Khawla Flanges is a well-respected manufacturer and supplier located in Muscat, Oman, known for crafting top-notch DIN 2566 PN16 Threaded Flanges that meet the rigorous demands of today’s piping systems. With a strong focus on precision, durability, and adherence to international standards, the company guarantees that each flange provides reliable performance and a long lifespan. Catering to industries like oil and gas, petrochemicals, water treatment, HVAC, and power generation, Khawla Flanges offers solutions designed for high-pressure and corrosive settings. Their DIN 2566 PN16 Threaded Flanges are easy to install, create secure connections, and boast exceptional strength, making them a go-to choice for various industrial applications.
Typically, DIN 2566 PN16 Threaded Flanges are made from high-quality carbon steel, stainless steel, or alloy steel, depending on what the application requires. Their chemical makeup features controlled amounts of chromium, nickel, molybdenum, and carbon, which enhance their strength and resistance to corrosion. These flanges showcase impressive mechanical properties, including high tensile and yield strength, good pressure-handling capabilities, and resistance to thermal stress and oxidation. Built for PN16 pressure ratings, they ensure secure, leak-free connections while maintaining structural integrity in high-temperature and corrosive environments, providing long-lasting durability and performance.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Neck | Raised face | Screws | Weight (7,85 Kg/dm3) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | Thread | D | b | k | h1 | d3 | d4 | f | Holes | Thread | d2 | Kg | |
| 15 | 21,3 | R 1/2 | 95 | 14 | 65 | 20 | 35 | 45 | 2 | 4 | M 12 | 14 | 0,613 |
| 20 | 26,9 | R 3/4 | 105 | 16 | 75 | 24 | 45 | 58 | 2 | 4 | M 12 | 14 | 0,91 |
| 25 | 33,7 | R 1 | 115 | 16 | 85 | 24 | 52 | 68 | 2 | 4 | M 12 | 14 | 1,1 |
| 32 | 42,4 | R 1 1/4 | 140 | 16 | 100 | 26 | 60 | 78 | 2 | 4 | M 16 | 18 | 1,6 |
| 40 | 48,3 | R 1 1/2 | 150 | 16 | 110 | 26 | 70 | 88 | 3 | 4 | M 16 | 18 | 1,78 |
| 50 | 60,3 | R 2 | 165 | 18 | 125 | 28 | 85 | 102 | 3 | 4 | M 16 | 18 | 2,43 |
| 65 | 76,1 | R 2 1/2 | 185 | 18 | 145 | 32 | 105 | 122 | 3 | 4 | M 16 | 18 | 3,18 |
| 80 | 88,9 | R 3 | 200 | 20 | 160 | 34 | 118 | 138 | 3 | 8 | M 16 | 18 | 4,12 |
| 100 | 114,3 | R 4 | 220 | 20 | 180 | 38 | 140 | 158 | 3 | 8 | M 16 | 18 | 4,47 |
| 125 | 139,7 | R 5 | 250 | 22 | 210 | 40 | 168 | 188 | 3 | 8 | M 16 | 18 | 6,13 |
| 150 | 165,1 | R 6 | 285 | 22 | 240 | 44 | 195 | 212 | 3 | 8 | M 20 | 22 | 7,92 |
Khawla Flanges, a leading supplier in Muscat, OMAN, offers an extensive selection of DIN 2566 PN16 Threaded Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2566 PN16 Threaded Flanges are commonly found in piping systems where welded connections aren’t practical or necessary. Their threaded design allows for quick and straightforward installation, making them perfect for low to medium-pressure applications. You’ll often see these flanges in water supply systems, fire-fighting networks, oil and gas pipelines, chemical processing facilities, HVAC systems, and industrial fluid handling operations. They’re also utilized in maintenance and repair tasks, proving their versatility and reliability across a range of settings.
Yes, we offer custom sizes for DIN 2566 PN16 Threaded Flanges to meet specific project needs. Our team at Khawla Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@khawlaflanges.com.
