Khawla Flanges, based in Muscat, Oman, stands out as a reputable manufacturer and supplier of top-notch Hastelloy Threaded Flanges designed for tough industrial applications. With a strong focus on precision engineering and compliance with international standards, the company delivers durable, corrosion-resistant solutions that can withstand harsh environments. Khawla Flanges prioritizes the selection of high-quality materials, employs modern production methods, and maintains rigorous quality control to guarantee outstanding product performance. Their Hastelloy Threaded Flanges are crafted for easy installation, ensuring leak-free connections and a long lifespan. With a commitment to customer satisfaction, timely delivery, and ongoing innovation, Khawla Flanges caters to a diverse clientele across Oman and the Gulf region.
Hastelloy Threaded Flanges are crafted from nickel-molybdenum-chromium alloys, which are renowned for their exceptional resistance to corrosion, pitting, and stress-related wear. The high nickel content provides stability in reducing environments, while chromium boosts oxidation resistance, and molybdenum enhances protection against severe chemical attacks. On the mechanical side, these flanges exhibit impressive tensile strength, hardness, and toughness, making them ideal for high-pressure and high-temperature applications. Their threaded design allows for secure fittings without the need for welding, ensuring structural integrity even under cyclic and dynamic loads. This blend of durability and corrosion resistance guarantees reliable, long-lasting performance in demanding industrial settings.
| Specification | ASTM B564 / ASME SB564 |
|---|---|
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Pressure Rating ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production Technique | Forged, Heat treated and machined |
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Manufacturer of | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. B.S: BS4504 , BS3293, BS1560, BS10 The other standard: AWWA C207; EN1092-1, GOST12820, JIS B2220; KS B1503, SABS1123; NFE29203; UNI2276 |
| Grades | Hastelloy c276, b2, x, c22 |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Hastelloy Threaded Flanges find their place in various industries where robust corrosion resistance and straightforward installation are crucial. Chemical processing plants rely on them for piping systems that manage aggressive acids, alkalis, and solvents. In the oil and gas sector, they are essential for high-pressure lines, offshore installations, and environments with sour gas. Power generation facilities depend on these flanges for their reliability in challenging conditions, ensuring safe and efficient operations. Their versatility makes them a preferred choice across multiple sectors, highlighting their importance in maintaining the integrity of critical systems.
Hastelloy threaded flanges are commonly applied where corrosion resistance and strength are needed. Common applications include the chemical process industry, oil and gas, power generation, and the pharmaceutical sector. Hastelloy threaded flanges are suitable for use with hazardous substances like acids, chlorides and alkalis in reactors, heat exchangers, and pressure vessels. Their pitting, stress corrosion and high ambient temperature resistance qualifies them for demanding conditions such as marine, wind and aerospace applications Hastelloy threaded flanges are utilized in equipment specialization where necessary that postpones and performance.
| ASME/ANSI B 16.5 | Threaded Flange |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| PRESSURE CLASS | 75, 150, 300, 400, 600, 900 |
| ASME/ANSI B 16.36 | Threaded Flange |
| PRESSURE CLASS | 300, 400, 600, 900, 1500, 2500 |
| BS 4504 SEC 3.1 | Hubbed Threaded Flange |
| PRESSURE CLASS | PN 2.5 TO PN 40 |
| BS 4504[PART 1] | Threaded Hubbed Threaded, |
| PRESSURE CLASS | PN 2.5 TO PN 400 |
| BS 1560 BOSS | Threaded Hubbed Threaded |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| BS10 | Threaded Flange |
| TABLE | D, E, F, H |
| DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
| PRESSURE CLASS | PN 6 TO PN 100 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
| Hastelloy C276 | 2.4819 | N10276 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
| Hastelloy C22 | 2.4602 | N06022 | NW 6022 | – | NiCr21Mo14W | – |
| Hastelloy B2 | 2.4617 | N10665 | – | – | – | – |
Yes, we offer custom sizes for Hastelloy Threaded Flanges to meet specific project needs. Our team at Khawla Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@khawlaflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
